- Place of Origin: Shandong, China (Mainland)
- Brand Name: TN-ORIENT
- Model Number: KX-SA
- Type: Plant
- Electricity Generator Type: Biomass Gasification
- Output Voltage (V): 440
- Model: KX-SA
- Usage: Power generation
- Rated Power Output: 30-2000kw
- Material Type: Any kind of biomass from agriculture and forestry
- Material Consumption: 25-1400kg/hour
- Power Comsumption: 0.08kw-100kw
- Certificate: CE ISO
- Warrenty: 18 months after delivery
- After Sale Service: Techincal Service Forever
- Supply Scope: Complete solution of gasfication plant and genset
Packaging & Delivery
|Packaging Details:||Export Packing|
|Delivery Detail:||within 60-90 days after payment|
I.Why Gasifier Biomass Power Plant
What would you do if an energy crisis begins today? Do you want to learn to create your own electricity,your own vehicle fuel,or reduce your home heating and cooling cost.
In today's world with the rise of natural disasters,terrorism and economic instability,the risk of a serious disaster occuring is high. Those of us with families have obilgation to provide for our loved ones and keep them safe.
Gasification is a proven tchnology that help millions of people surive druing the second world war. Gasification allowed farmers to grow crops,food tranported and electricity to be generated.
Our circulating fludized bed downdraft gasifier is an alternative energy technology that converts biomass material into energy. Biomass is mainly composed to of carbon,hydrogen,and oxygen.When this elements meet in a controlled high temperature state.they comebine together to become hydrogen gas,methane,and carbon monoxide. All of these gases are combustible.
In the hands of a knowledgeable operator ,our extensively proven desigh biomass gasifiers will enable the uses to power engines for "off grid" power generation.
II.What Kind of Material Available for Gasifier Power Biomass Plant
Our gasifier power plant can use any kind of biomass from agriculture and foretry waste as material to produce clean biogas for power generation.
III.How The Gasifier Power Biomass Plant Work
IV.How Much kwh Available and What is Specification for Each Gasfier Biomass Power Plant
Our gasifier power plant ranges capacity from 20kw to 600kw for single power plant and double or triple the plant the power generating are available up to 2MW
Model of Gasifer
|Material Required||Any biomass with moisture <20% and size <30mm|
Heat Value of Biogas
|Ash Removal Type||Mechanicle dry type|
|Tar Purification Type||Mechanicle dry type|
CH4--1-3%, CO--14-18%, H2--10-15%, CO2--10-16%, CnHm--1-1.4%,
|Model of Genset||20GFT||30GFT||50GFT||100GFT||200GFT||300GFT||400GFT||250GFT||300GFT|
Output Rated Power
|230/400V or customerized|
Number of Genset
V.What Is Assembling Plant Like
VI.What Any Other Special for Gasifier Biomass Power Plant
----One tough screen display which can realize automatic control
----You can inspect inside of the burning chamber at any time
----Automatic feeding,autmatic ash dishcharging and automatic water cooling but the water don't conatct the biogas
VII.How Big Is You Company
VIII.Packages and Container Loading for Our Gasifier Power Plant
IX.What Advantages Do Your Gasifer Power Plant Have
1.Robust construction guarrantees the long service life and service life would be over 20 years.
2.Compact structure needs less occupying area and it saves much cost on the shelter.For same output kwh our gasifier biomass power plant would be save 2-3 times space comparing to others from China.
3. Biogas produced from our gasifier biomass power plant get higher calorific value which can get 1100-1300Kcal/m3 but others from China is just 900-1100Kcal.
4.Our gasifier biomass power plantou adopts combined mechanical refrigeration and centrifugal seperation tech to cool the gas and remove the tar and the water would not contact the gas directly. In this sense our gasfier power plant would not cause any water polution. While many gasifier power plant from China adopts water spaying to cool the gas and remove the tar it would cause bad water pollution.And you must pay big money to deal with polluted water.
5.Fully automatic control can realize only one man to operate the complete system and this would save big money on the employee.
6.Most crucially our gasifier biomass power plant can realize 24hours X 365 days working with non-stop even when the replacing the filtering medium and discharging the water you don't have to stop the gasifier plant.
1.What kind of Material can be used as for material?
Any biomass from agriculture and forestry such as grain straw,rice husk,peanut shell,crop stalk,EFB,tree leaf,cut-off,wood chips,wood shavings,pellets,ect. and all the processed organic objectives or biomass mixed with 30% inorganic objectives from MSW.
2.How is about the power convertion efficiecy?
Commonly about 1.2-1.5 kg biomass can generate 1kwh elecctrity
3.Do you offer the overseas service?
Yes we offer the offer the overseas guidence of installation,commissioning and traninng
4.What is the terms of payment?
50% as deposit by T/T and balance paid before shippment
5.How long for the delivery time
60 days after receipt of the deposit for plant≤300kw and 90 days after receipt of deposit for plant 400-600kw
6.How is your warranty?
For the gasfier plant 1 year warranty after commissioning and during the warranty time any breakdown caused by the quality seller would replace broken part or whole machine at seller's expense.Breakdown caused by the fualt operation would not deemed into warranty.
For the genset 1 year warranty or 1500 working hours which come first and during the warranty time any breakdown caused by the quality of the machines seller word replace broker part or whole machines at seller's expense.Normally spare parts and the breakdown caused fualt operation would not deemed into warranty
Interested and Want An Offer
